JL3100 Series Banknote Fitness Sorting and Binding Mahine

After years of market research and analysis, JL3100 has been carefully designed, to ensure optimal operational ergonomics and environment for the user. The design is carried out based on the precise positioning of the product appearance and is equipped with an automatic dust proof door, which is more suitable for a safe and comfortable user working position.


  • Ergonomically and Environmentally Designed
  • Intuitive User Interface
  • Efficiency and Productivity Improvement
  • CQC 2
  • CE 1
  • RoHS 2

Technical Specification

Capacity Hopper:1000 notes Stacker:200 notes*2
Reject Stacker:100 notes
NV technology CIS UV MG IR
Speed Range 1200 notes/min
Binding: 12binds/min
Banknote Size Range Width:53-85mm, Length:115-180mm
Display 9-inch touch display
Connectivity RJ45 RS232 USB2.0
Operating System LINUX
Power Supply 220V-240V 50/60Hz
Power Consumption 100W
Dimensions(W*D*H) 495*396*391mm(JL3100)
Weight 32kg(JL3100)
Certification CQC ROHS CE
Accessories Additional Currencies, Remote Display, Integral Printer,
Clearance Program, Serial Number Printing
Support Currencies CNY EUR INR SAR AED BUK GHC TZS UZB KHR KZT SKR PKR Multi-Currencies Capabilities up to 100 Currencies


Remarkable Features of Our Products

All-in-one cash processing equipment increases your ROI.

Custom Configurations for Your Real Needs

From the beginning of the consultation, we will have a detailed understanding of the site layout and staffing. We provide 4 configurations and custom solutions according to the actual application scenario to meet the workflow and requirements. We are dedicated to helping maximize cash processing efficiency.
