Four Configurations Available
The JL305 series offers 4 configurations to suit banknote processing requirement.
Software System
LINUX operation system makes JL305 became extensible and configurable. Printer and computer can be connected to our sorting machine with a cable. Users are able to read, upload, print operator number, working time and banknote information, and also can save the information needed to computer. With our software, JL305 is capable of serial number reading, recognition and comparison, black list setting, counterfeit currency tracing and management, and bar code reading.
| Capacity: | Hopper: 1000 notes |
| NV Technology: | CIS, UV, Magnetic, IR |
| Speed Range: | Counting: 1200 notes/min Sorting: 1000 notes/min Serial Number Reading: 1000 notes/min |
| Banknote Size Range: | Width: 53-85mm, Length: 115-180mm |
| Display: | 9.7″ TFI Color Display |
| Interface: | LAN, RS232, USB |
| Operating System: | LINUX |
| Power Supply: | 200-240V 50/60Hz |
| Power Consumption: | 440W |
| Dimensions: | 1074mm (W) × 445mm (D) × 470mm (H) |
| Weight: | 70kg |
| Certification: | CQC CB RoHS WEEE CE ECB |
| Accessories: | Additional Currencies, Remote Display, Integral Printer, Clearance Program, Serial Number Printing. |
| Support Currencies: | CNY EUR USD INR ZAR SAR AED GBP TZS PLN GHC GMD BUK JPY HKD GHF CAD KRW THB ALL NOK SEK AUD IRR SYP |
All-in-one cash processing equipment increases your ROI.
Stackers push-out banknote automatically when banknote quantity reach preset batch value, which improves sorting productivity with 50%. This technology with patent certification to ensure “Non-Stop Operation”
Linear and roller banknote transport structure with patent certification and fully open banknote transport passage, which can be used to deal with damaged, old and small denomination banknote. It makes an easy maintenance and a quick jam recovery.
Modularization multi-sensor recognition technology helps to identify high quality counterfeit banknote and forgery banknote with high-precision.
Serial number identification and tracking are available and cash circulation management system is optional.
The LAN, RS-232 and USB interface extend the connectivity of JL305, which can be connected with external LCD, printer and PC for sorting report checking, printing and upgrading, to realize centralized management.
From the beginning of the consultation, we will have a detailed understanding of the site layout and staffing. We provide 4 configurations and custom solutions according to the actual application scenario to meet the workflow and requirements. We are dedicated to helping maximize cash processing efficiency.
Julong's aim is to provide products and services that help make the currency circulates in a safe and fast way.
